Sun Bicycles Atlas Transit

Sun Bicycles Atlas Transit
  • Color: Yellow
  • Color: Black
$849.99
Color:
Size: One Size
Wheel Size: 24-inch
Please select options Unavailable
This item is not permitted to be shipped, however it can be purchased online and picked up. We will contact you when your order is ready for pickup which may be UP TO 3 DAYS from the time your order is placed for bicycles. Please wait for that confirmation before coming to the store.

Details

The Atlas Transit is our medium duty trike is perfect for hauling groceries from the local market or transporting packages around a warehouse. The frame is designed with the same Low-Step as our Traditional trike making for easy on and off access. Along with a complement of durable components, the 24" version is customizable with 3 different wheel styles. The 20" SD version comes stock with alloy wheels, includes a Sun custom trike saddle with adjustable backrest, and Velcro toe straps for secure foot placement.

- Wheels sold separately
- High-tensile steel Low-Step frame
- Single-speed drivetrain (Additional gearing options available separately)
- Alloy linear-pull front brake with parking lock (Additional brake options available separately)
- One-piece steel crank with sealed bottom bracket
- 24" x 1.95" multi-condition tires
- 13" high-rise steel handlebar and threadless MX stem, rubber grips
- Sun XL trike saddle with heavy-duty steel base
- Steel chain guard and front fender
- Viny coated heavy-duty steel wire basket

Wheel options:
- Skyway mags
- Alloy rims with 14g stainless steel spokes
- Heavy duty steel rims with 12g UCP steel spokes
- MSRP shown includes Skyway mags

Weight:
- Trike Weight: 56 Lbs (with Skyway mags)
- Rider Weight Limit: 250 Lbs.
- Basket Weight Limit: 50 Lbs. (Not Designed for People or Pets)
- Recommended Fit: 5'0" to 6'2"

Geometry
Sizes:
Frame Size17"
Seat Tube, Center To Top A 17"
Top Tube, Effective B 27.5"
Top Tube, Actual B4 26"
Head Tube C 5.5"
Seat Tube Angle D 70°
Head Tube Angle E 70°
Chainstay F 23"
Wheelbase G 46.3"
Bottom Bracket Drop H 1.9"
Fork Offset I 1.8"
Axle To Crown K 14.5"
Step-Thru / Standover N 13.25"
Minimum Step Through O 13.25"
Minimum Saddle To Ground 27.5"
Minimum Saddle To Pedal, Trike 27.5"
Overall Length (Trike) U 71.5"
Overall Width (Trike) V 30.25"
Overall Height (Trike) W 45"
Wheel Size 24"
Crank Length 170mm
Stem Length 50mm
Handlebar Width 31.5" Wide / 13" Rise

Specs

Frame High-Tensile Steel, TIG-Welded, Frame Rear Unit: High Tensile Steel, TIG-Welded, Disc and Der Compatible
Fork 1-1/8" Hi Tensile Steel, Curved Legs, Double Eyelets
Wheels Ordered Separately
Tires 24 x 1.95", Black Wall
Bottom Bracket Steel for OPC, Caged Bearings with Seal
Crankset One-Piece Heavy Duty Hot Forged Steel, 170mm
Cassette/Freewheel 20T x 1/2" x 1/8"
Chain Taya 1/2" x 1/8", 130 Links
Brakes Alloy, Linear Pull
Brake Levers Alloy, Linear Pull w/ 3-Finger Lever and Parking Lock
Handlebars Steel, 31.5" Wide 13" Rise x 22.2mm Clamp
Tape/Grips Heavy Duty Rubber, 125mm
Stem Alloy, Threadless, 28.6 x 50mm x 0 deg x 22mm Clamp
Headset Steel, Semi Cartridge Bearings, 28.6 x 34 x 30mm
Seatpost Steel w/o Clamp, W/Anti-Slip Knurling, 28.6 x 12"
Saddle Deluxe Cruiser, Double Coil Spring Suspension
Pedals Slip Resistant Top, 1/2"
Accessories & Extras Chain Guard: Steel, Painted, Basket: Heavy Duty Steel, Black Vinyl Coated, 21" Long x 15" Wide x 9" High, Front Fender: Steel, W/Single Strut, Painted

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Yellow / One Size / 24-inch 888571014592 670206
Black / One Size / 24-inch 888571014585 670205 670205
